Wholesale Autonomous Home Lawn Care Robot Wheel Lawn Mower for Sale

Classification: 550MM
Details

Key attributes

feature
2-Stroke, Height Adjustable Handles, Self Propelled, Telescopic Handle
grade
Diy
voltage
24 V
power source
Gasoline engine
place of origin
Shandong
customized support
OEM, ODM
model number
SKK55-B
brand name
CF
engine displacement
224/189cc
forward speed
0~5 adjustable
warranty
1
Product name
Remote Control Lawn Mower
Dimensions (LxWxH)
1050*900*450 mm
Model
SKK55-B
Structural quality
160kg
Grass height
30~120 adjustable

Packaging and delivery

Port of dispatch
Qingdao Port
Selling Units
Single item

Configuration and features:

(1) The power is Loncin gasoline engine, gasoline-electric hybrid, with its own power generation and power supply system, which is automatically charged during work.

(2) Driven by an energy-saving brushless motor, it can turn around at zero angle, and mow grass in forward, backward and turning directions. (3) All gears strengthen the gearbox, which can bear 300kgs. (4) Equipped with patented collision protection technology, it can automatically stop when it encounters obstacles in front while mowing, which can effectively protect the machine. (5) The control adopts industrial remote control device, which is easy to operate, low failure rate, and the remote control distance is 200 meters. (6) The track adopts internal steel frame steel wire and external engineering rubber design, which is wear-resistant and durable. (7) The body is low and the height is 45cm. It has good passability and is not easy to roll over. It is especially suitable for: mountainous areas, hills, terraced fields, greening, orchard mowing. (8) Adjustment: The height of the grass can be adjusted from 3 to 12 cm, and the mowing speed can be adjusted by remote control.



HOST

BATTERY
Project Name
Unit
Parameter Value

Project Name
Unit
Parameter Value
Model
/
SKK55-B

Battery Type
/
Dry Battery
Dimensions (L×W×H)
mm
1050*900*450

Remote Control Battery Voltage
V
24
Structural Quality
kg
160

Walking Battery Voltage
V
24
LFuel tank capacity
6L
120

Charging Type

Automatic charging when the generator is working
SUPPORTING POWER

TRAVEL MOTOR
Project Name
Unit
Parameter Value

Project Name
Unit
Parameter Value
Model Name

LC1P75F-1/MA190

Rated Power
Kw
0.7
Structure Type

Horizontal bar four-stroke

Operating Voltage
V
24
Calibration Power
Ps
9

Rotating Speed
r/min
2000
Rated Speed
r/min
3600/2800

Walking Speed
Km/h
0~5 adjustable
Fuel Type

Gasoline

Remote Control Distance
m
≤200
Average Fuel Consumption
L/H
1-1.5

Working Slope
Spend
≤45
Displacement
CC
224/189




MATCHING LAWN MOWER

Configuration and Features
Project Name
Unit
Parameter Value

Project Name
Unit
Parameter Value
Number Of Tools
pcs
2

Rated Power
kw
1.5
Tool Speed
r/min
2000-3000




Mowing Width
mm
550




Cutting Height
mm
70
