Robot Lawn Mower Petrol Rubber Track Automatic Lawn Mover Remote Control 360 Degree Rotating Mowers

Classification: GPS Style
Details

Key attributes

grade
Diy
power source
Gasoline engine
warranty
1
feature
4-Stroke, Self Propelled, Single cylinder
engine displacement
452cc
voltage
48 V
customized support
OEM, ODM
place of origin
Shandong
model number
GPS Style
brand name
CF
forward speed
0~5 adjustable
Product Name
Remote Control Lawn Mower
Dimensions (LxWxH)
1140*1140*620 mm
Model
GPS Style
Structural Quality
280 kg
Grass Height
30~150 adjustable

Packaging and delivery

Selling Units
Single item
Single package size
XX cm


Configuration and features :1. Powered by Loncin gasoline engine, gasoline-electric hybrid power, with built-in power generation and power supply system, and automatic charging during work. 2. The motor adopts a DC brushless motor of CNC machine tool type, which is energy-saving and durable, and suitable for long-term work. 3. Automatic braking when parking, suitable for steep slope operations. 4. The generator uses a marine grade generator with extremely low failure rate and long life. 5. The control adopts industrial remote control device, which is simple to operate, low failure rate, and the remote control distance is 200 meters. 6. The track adopts internal steel frame steel wire and external engineering rubber design, which is wear-resistant and durable. 7. Reinforced chassis, low body, tank-like design, climbing hills and crossing ditches are its strengths; especially suitable for: dams, orchards, hills, terraces, photovoltaic power generation, and greening and mowing. 8. Adjustment: The grass height is adjustable from 3 to 15 centimeters, and the mowing speed is adjustable by remote control.

HOST

BATTERY
Project Name
Unit
Parameter Value

Project Name
Unit
Parameter Value
Model
/
GPS Style

Battery Type

Dry Battery
Dimensions (L×W×H)
mm
1140*1140*620

Walking Battery Voltage
V
48
Structural Quality
kg
280

Remote Control Battery Capacity
Ah
24
EQUIPPED WITH TRANSPORT BUCKET

Remote Control Battery Voltage
V
24
Dimensions (L×W×H)
mm
1260*1200*1160

Walking battery capacity
Ah
20*4
Load capacity
kg
≤400

Charging Type

Automatic charging when the generator is working
SUPPORTING POWER

TRAVEL MOTOR
Project Name
Unit
Parameter Value

Project Name
Unit
Parameter Value
Model Name

LC1P92F-1

Rated Power
Kw
1.6
Structure Type

Horizontal bar four-stroke

Operating Voltage
V
48
Calibration Power
Ps
16

Rotating Speed
r/min
1000-3000
Rated Speed
r/min
3600

Walking Speed
Km/h
0~5 adjustable
Fuel Type

Gasoline

Remote Control Distance
m
≤200
Average Fuel Consumption
L/H
1.5-2

Working Slope
Spend
≤50
Displacement
CC
452




MATCHING LAWN MOWER

DYNAMO
Project Name
Unit
Parameter Value

Project Name
Unit
Parameter Value
Number Of Tools
pcs
2

Rated Power
kw
5
Tool Speed
r/min
2500-3000




Mowing Width
mm
800




Cutting Height
mm
30~150 Adjustable
